| ブランド名: | Sinuo |
| モデル番号: | SN553-EV203 |
| MOQ: | 1 |
| 価格: | 交渉可能 |
| 支払条件: | T/T |
| 供給能力: | 1 1ヶ月あたりにセット |
Vibration testing is the act of exciting or shocking a component or device to see how it would react in a real environment. The application range of vibration test is extremely wide, from industrial products such as circuit boards, aircraft, ships, rockets, missiles, automobiles and household appliances.
Sinuo can provide you with the whole excitation and testing scheme, and prove the quality of the products for you according to national and international standards, such as GB, GJB, UL, JIS, DIN, ISO, BS, MIL, IEC and ASTM.
| Model | EV203 |
|---|---|
| Vibration Generator | VG300/40 |
| Frequency (Hz) | 2-2500 |
| Max Exiting Force (kg.f) | 300 |
| Max. Displacement (mmp-p) | 38 |
| Max. Acceleration (g) | 100 |
| Max. Velocity (cm/s) | 120 |
| Payload (kg) | 120 |
| Armature Mass (kg) | 3 |
| Armature Diameter (mm) | φ150 |
| Cooling Method | Forced Air Cooling |
| Vibration Generator Weight (kg) | 460 |
| Vibration Generator Dimension L*W*H (MM) | 750*555*670 |
| Power Amplifier | Amp3k |
| Cooling Method | Forced Air Cooling |
| Power Amplifier Weight (kg) | 250 |
| Power Amplifier Dimension L*W*H (MM) | 800*550*1250 |
| Utility Requirements | 3-phase AC380V ±10% 50Hz |
