| ブランド名: | Sinuo |
| モデル番号: | SN882B |
| MOQ: | 1 |
| 価格: | Customized |
| 支払条件: | T/T |
| 供給能力: | 20 sets/month |
| Parameter | Specification |
|---|---|
| Model | SN882B |
| Sample Size | WDH=1100*600*500mm (Inner chamber dimensions) |
| Sample Placement Area | WDH=1140*600*500mm (Chamber type) |
| External Dimensions | Approximately 1400*1750*750mm (W*H*D) |
| Lamp Center Distance | 70mm |
| Sample to Lamp Distance | 50±3mm |
| Nozzle Quantity | 4 pieces (top row) |
| Spray Pressure | 70-200Kpa (adjustable) |
| UV-B Lamp Irradiation | 0-0.9 W/m² at 313nm (adjustable) |
| UV-A Lamp Irradiation | 0-0.9 W/m² at 340nm (adjustable) |
| Lamp Length | 1220mm |
| Lamp Power | 40W |
| Lamp Lifespan | More than 1600 hours |
| Number of Lamps | 8 pieces (top row), UV-A/UV-B selectable (default: UV-A) |
| Weight | 80kg |
| Maximum Power | 3KW |
| Maximum Current | 15A |
| Power Requirements | AC 220V single-phase, ±10% voltage fluctuation, 50/60Hz frequency, TN-S or TT power supply, protective grounding resistance less than 4Ω |
