IEC 60695 Flame Test Chamber Horizontal and Vertical Flame Test Chamber 500W 50W

ブランド名:	Sinuo
モデル番号:	SN771
MOQ:	1
価格:	Customized
支払条件:	T/T
供給能力:	30セット/月

詳細情報

製品説明

詳細情報

起源の場所:

中国

証明:

Calibration Certificate (Cost Additional)

適用規格:

IEC 60695-11-3および等。

制御方法:

PLCとタッチスクリーン

50Wガスの流れ:

105±5ml/min

50W炎テスト角度:

0°、45°

500Wガスの流れ:

965±30ml/min

500W炎テスト角度:

20°

燃焼時間:

0-9999X0.1Sは、前もって調整することができる

炎の塗布:

0-9999回は、前もって調整することができる

パッケージの詳細:

合板ケース

供給の能力:

30セット/月

ハイライト:

IEC 60695 flame test chamber

horizontal vertical flame tester

500W flammability testing equipment

製品説明

IEC 60695 Flame Test Chamber - Horizontal and Vertical Flame Testing

This Horizontal and Vertical Flammability Tester is designed to assess the ignitability and flame propagation characteristics of plastic and non-metallic materials used in electrical and electronic products.

Compliance Standards

Conforms to UL94, IEC60695-11-2, IEC60695-11-3, IEC60695-11-4, IEC60695-11-10, IEC60695-11-20.

Equipment Overview

This testing chamber accurately simulates the influence of small open flames at the early stage of a fire, helping manufacturers determine the fire hazard potential of materials used in household appliances, IT equipment, audio/video devices, and other products.

Applications

Plastic materials and non-metallic solid materials
Foam plastics with density ≥ 250kg/m³ (tested as per ISO845)
Horizontal and vertical burning tests for comparative combustion characteristics

Key Features

Integrated inlet ignition system with a flame delay of 0.1 seconds for stable ignition
Matte black background for optimal flame visibility and contrast
High-precision digital timers for accurate flame application and afterflame/afterglow measurement
Multi-functional flame measuring gauge for adjustable flame length and positioning
Full stainless steel enclosure ensures durability and corrosion resistance
Large observation window for safe and clear test monitoring
Compact design incorporating international best practices
Complies with multiple global safety testing standards

Technical Parameters

Test Flame Calibration	Specifications
Distance between burner port to temperature measuring copper block	50W: 10±1 mm; 500W: 55±1 mm
Thermocouple	American original Omega φ0.5 armour nickel-chromium/nickel aluminum wire K-Thermocouple, temperature resistance 1100°
Temperature rise time from 100±2° to 700°±3°	50W: 44±2S; 500W: 54±2S
Flame height	50W: 20±2mm (no internal and external flame); 500W: Inner flame: 40±2mm, Outer flame: 125±10mm
Temperature measuring copper head	50W: Ф5.5mm±0.01mm, weight before drilling 1.76±0.01g; 500W: Ф9mm±0.01mm, weight before drilling 10±0.05g
Back Pressure Water Column Height of U-Shaped Pressure Gauge	50W: 10mm; 500W: 125±5 mm
Test Angle	50W: 0°,45°; 500W: 20°

Parameter	Specification
Working voltage	120V/60Hz
Power/grade	50W and 500W double power switching
Control operation mode	PLC control, 7 inch color touch screen operation, with infrared remote controller
Blast burner standard	IEC60695-11-3/IEC60695-11-4/10, UL94, etc. inner diameter: Φ9.5±0.3mm, length: 100mm, made of brass
Gas pressure	0.1MPa
Gas flow	50W: 105±5ml/min or 18±1mm; 500W: 965±30ml/min or 117±3 mm, flow meter adjustment
U type pressure gauge back pressure water column height	50W: 10mm; 500W: 125±5 mm
Test angle	50W: 0°,45°; 500W: 20°
Burning time	0-9999X0.1S Can be preset
Burning times	0-9999 times, Can be preset
Residual flame/Residual glow	0-9999X0.1S Can be displayed
